READ MOREHow does the hybrid inverter manage power from multiple sources ?
The hybrid inverter manages power from multiple sources—such as solar panels, wind turbines, batteries, and the grid—through a combination of advanced power electronics and intelligent energy management algorithms. Here’s how it typically works:
The inverter converts the direct current (DC) generated by solar panels and wind turbines into alternating current (AC) suitable for household or grid use. It continuously monitors the output from these renewable sources and maximizes their utilization.
The inverter controls the charging and discharging of batteries. During periods of excess power generation (e.g., sunny or windy days), it stores surplus energy in the batteries. During periods of low generation or high demand, it discharges the stored energy to supply the load.
The inverter can import electricity from the grid when renewable generation and battery storage are insufficient to meet demand. Conversely, if the generated renewable energy exceeds household consumption and battery capacity, the inverter can export the surplus electricity back to the grid.
Intelligent Energy Management
The user can set priorities for power sources. For instance, the system can be configured to prioritize solar and wind energy over grid power to maximize the use of renewable energy.
The inverter dynamically adjusts the power supply based on real-time demand. It can shift loads to different power sources to optimize efficiency and cost-effectiveness.
Leveraging the peak-shaving feature, the inverter can charge the batteries during off-peak hours when electricity rates are lower and discharge them during peak hours to minimize electricity costs.
Monitoring and Control
Built-in WIFI and Bluetooth allow the user to monitor and control the system remotely via a dedicated app. This helps in tracking performance, setting preferences, and receiving alerts.
The inverter continuously collects and analyzes data from all connected sources and loads. It uses this data to make real-time decisions on the optimal distribution of power.
The hybrid inverter manages power from multiple sources through sophisticated integration, intelligent energy management, and real-time monitoring and control. By prioritizing renewable energy, optimizing battery usage, and leveraging time-of-use pricing, it ensures efficient, cost-effective, and reliable power supply while providing backup during grid failures.
How does Hybrid Inverter prioritize between using solar power, battery storage, and grid power?
A hybrid inverter prioritizes between using solar power, battery storage, and grid power through a set of predefined algorithms and user-configurable settings. Here's how the prioritization typically works:
Solar Power Utilization
Primary Source: Solar power is generally prioritized as the primary source of energy. The inverter first uses the available solar power to meet the immediate energy needs of the household or facility.
Direct Consumption: If the solar power generation is sufficient, it directly powers the connected loads (appliances, lights, etc.).
Surplus Management: If the solar generation exceeds the immediate consumption, the surplus energy is directed to charge the battery storage.
Battery Storage
Charging: When solar power is in excess, the inverter charges the batteries. The charging process is managed to ensure the batteries are not overcharged and are kept within their optimal operating range.
Discharging: When solar power is insufficient (e.g., during nighttime or cloudy days), the inverter discharges the stored energy from the batteries to meet the energy demand.
Optimal Utilization: The inverter may also discharge the batteries during peak hours when the electricity rates are high, even if the grid is available. This is part of the peak-shaving strategy to reduce electricity costs.
Grid Power
Supplementary Source: Grid power is used as a supplementary source. It is typically the last resort when both solar power and battery storage are insufficient to meet the demand.
Off-Peak Charging: The inverter can be programmed to use grid power to charge the batteries during off-peak hours when electricity rates are lower. This ensures that the batteries are fully charged for use during peak hours or when solar power is unavailable.
Backup: Grid power acts as a reliable backup to ensure uninterrupted power supply, especially when renewable sources are not available and battery storage is depleted.
Configurable Settings and User Preferences
Priority Settings: Users can configure the priority settings based on their specific needs and preferences. For example, they can set the system to maximize solar usage, minimize grid dependency, or focus on cost savings by leveraging time-of-use tariffs.
Emergency Backup: In case of a grid outage, the inverter prioritizes battery power to provide uninterrupted supply to critical loads.
Smart Management and Automation
Real-Time Monitoring: The inverter continuously monitors the power generation from solar panels, the state of charge (SoC) of the batteries, and the power consumption.
Dynamic Adjustment: Based on the real-time data, the inverter dynamically adjusts the power flow between solar panels, batteries, and the grid to optimize efficiency and cost-effectiveness.
Remote Control: Through built-in WIFI and Bluetooth, users can remotely monitor and control the system, making adjustments as needed based on real-time information.
The hybrid inverter prioritizes the use of solar power first to maximize the use of renewable energy. Battery storage is used next, both for storing excess solar energy and providing power during periods when solar energy is not available. Grid power is used as a last resort or to charge the batteries during off-peak times. User-configurable settings and intelligent energy management algorithms ensure that the system operates efficiently, cost-effectively, and reliably.
